Depends on the obstacle.
At UWB frequencies, certain materials are UWB transparent (mostly) and other materials block it completely.
It will usually go through fabric, paper, wood (if not too thick or wet), drywall/gypsum, glass (if not leaded or metal coated), ceiling tile, plastics, etc.
It will not go through water, masonry, concrete, metals, humans, animals, wire mesh, and metal screen.
That sounds very doable.
Here is an example of our system being used to perform music more than 3 years ago. The stages the two “drummers” are standing on are made from 3/4" plywood and contain 28 anchors inside them. The UWB system is measuring the location of the wrist tags and that information, along with inertial data, is used to real time create sounds. The tags operated at 240 Hz, very high rate, to minimize latency.
The point is that carpet plus 3/4" plywood of the deck was no problem. Wood does have water content, and it did attenuate the signals some amount, but it wasn’t overly large.
We have also done a lot of through the walls UWB work. In standard commercial construction, using thin steel studs and gypsum drywall, the system penetrates the walls pretty well. Here is a quick demo video showing system performance penetrating a number of walls:
Each wall is metal studs on 16 inch centers with two layers of 5/8" drywall and paint.
If the walls are concrete or CMU block, then UWB signal is generally blocked entirely. If the walls have metal foil insulation inside them, that will also usually block the signal. So it really depends on the nature of the materials to assess how well UWB will track in any given situation.
The best way to visualize the UWB signal is a super elongated rugby ball with the tips at each node and the middle diameter being about 30 cm. If the things blocking the signal are covering too much of the 30 cm disc, then the signal may not get through. So a steel stud in the middle between nodes is not a problem, but a steel stud right in front of a node will be a major problem.
Mike Ciholas, President, Ciholas, Inc
